Taro小程序自定义顶部导航栏功能的实现

微信自带的顶部导航栏是无法支持自定义icon和增加元素的,在开发小程序的时候自带的根本满足不了需求,分享一个封装好的组件,支持自定义icon、扩展dom,适配安卓、ios、h5,全面屏。
我用的是京东的Taro多端编译框架写的小程序,原生的也可以适用,用到的微信/taro的api做调整就行,实现效果如下。

在这里插入图片描述
在这里插入图片描述

1、NavBar.js

import Taro from '@tarojs/taro';
import React, { Component } from 'react'
import { View } from '@tarojs/components';
import { isFunction } from '../../utils/index' //判断是否为函数,可以用loadsh的_isFunction,也可以自己封装。
import './NavBar.less';


function getSystemInfo () {
 if (Taro.globalSystemInfo && !Taro.globalSystemInfo.ios) {
  return Taro.globalSystemInfo;
 } else {
  // h5环境下忽略navbar
  if (!isFunction(Taro.getSystemInfoSync)) {
   return null;
  }
  let systemInfo = Taro.getSystemInfoSync() || {
   model: '',
   system: ''
  };
  let ios = !!(systemInfo.system.toLowerCase().search('ios') + 1);
  let rect;
  try {
   rect = Taro.getMenuButtonBoundingClientRect ? Taro.getMenuButtonBoundingClientRect() : null;
   if (rect === null) {
    throw 'getMenuButtonBoundingClientRect error';
   }
   //取值为0的情况 有可能width不为0 top为0的情况
   if (!rect.width || !rect.top || !rect.left || !rect.height) {
    throw 'getMenuButtonBoundingClientRect error';
   }
  } catch (error) {
   let gap; //胶囊按钮上下间距 使导航内容居中
   let width = 96; //胶囊的宽度
   if (systemInfo.platform === 'android') {
    gap = 8;
    width = 96;
   } else if (systemInfo.platform === 'devtools') {
    if (ios) {
     gap = 5.5; //开发工具中ios手机
    } else {
     gap = 7.5; //开发工具中android和其他手机
    }
   } else {
    gap = 4;
    width = 88;
   }
   if (!systemInfo.statusBarHeight) {
    //开启wifi的情况下修复statusBarHeight值获取不到
    systemInfo.statusBarHeight = systemInfo.screenHeight - systemInfo.windowHeight - 20;
   }
   rect = {
    //获取不到胶囊信息就自定义重置一个
    bottom: systemInfo.statusBarHeight + gap + 32,
    height: 32,
    left: systemInfo.windowWidth - width - 10,
    right: systemInfo.windowWidth - 10,
    top: systemInfo.statusBarHeight + gap,
    width: width
   };
   console.log('error', error);
   console.log('rect', rect);
  }

  let navBarHeight = '';
  if (!systemInfo.statusBarHeight) {
   //开启wifi和打电话下
   systemInfo.statusBarHeight = systemInfo.screenHeight - systemInfo.windowHeight - 20;
   navBarHeight = (function () {
    let gap = rect.top - systemInfo.statusBarHeight;
    return 2 * gap + rect.height;
   })();

   systemInfo.statusBarHeight = 0;
   systemInfo.navBarExtendHeight = 0; //下方扩展4像素高度 防止下方边距太小
  } else {
   navBarHeight = (function () {
    let gap = rect.top - systemInfo.statusBarHeight;
    return systemInfo.statusBarHeight + 2 * gap + rect.height;
   })();
   if (ios) {
    systemInfo.navBarExtendHeight = 4; //下方扩展4像素高度 防止下方边距太小
   } else {
    systemInfo.navBarExtendHeight = 0;
   }
  }

  systemInfo.navBarHeight = navBarHeight; //导航栏高度不包括statusBarHeight
  systemInfo.capsulePosition = rect; //右上角胶囊按钮信息bottom: 58 height: 32 left: 317 right: 404 top: 26 width: 87 目前发现在大多机型都是固定值 为防止不一样所以会使用动态值来计算nav元素大小
  systemInfo.ios = ios; //是否ios
  Taro.globalSystemInfo = systemInfo; //将信息保存到全局变量中,后边再用就不用重新异步获取了
  //console.log('systemInfo', systemInfo);
  return systemInfo;
 }
}
let globalSystemInfo = getSystemInfo();
class NavBar extends Component {
 constructor(props) {
  super(props);
  this.state = {
   configStyle: this.setStyle(globalSystemInfo)
  };
 }
 static options = {
  multipleSlots: true,
  addGlobalClass: true
 };

 UNSAFE_componentWillMount () {
  //获取高度
  // let query = Taro.createSelectorQuery().in(this.$scope)
  // query.select('.lxy-nav-bar').boundingClientRect(rect=>{
  //  const navHeight = rect.height
  //  this.props.personalHomeMod.changeState('navHeight',navHeight)
  // 	// console.log('navHeight',toJS(this.props.personalHomeMod.state))
  // }).exec()
 }
 componentDidShow () {
  if (globalSystemInfo.ios) {
   globalSystemInfo = getSystemInfo();
   this.setState({
    configStyle: this.setStyle(globalSystemInfo)
   });
  }
 }
 handleBackClick () {
  if (isFunction(this.props.onBack)) {
   this.props.onBack();
  } else {
   const pages = Taro.getCurrentPages();
   if (pages.length >= 2) {
    Taro.navigateBack({
     delta: this.props.delta
    });
   }
  }
 }
 handleGoHomeClick () {
  if (isFunction(this.props.onHome)) {
   this.props.onHome();
  }
 }
 handleSearchClick () {
  if (isFunction(this.props.onSearch)) {
   this.props.onSearch();
  }
 }
 static defaultProps = {
  extClass: '',
  background: 'rgba(255,255,255,1)', //导航栏背景
  color: '#000000',
  title: '',
  searchText: '点我搜索',
  searchBar: false,
  back: false,
  home: false,
  iconTheme: 'black',
  delta: 1
 };

 setStyle (systemInfo) {
  const { statusBarHeight, navBarHeight, capsulePosition, navBarExtendHeight, ios, windowWidth } = systemInfo;
  const { back, home, title, color } = this.props;
  let rightDistance = windowWidth - capsulePosition.right; //胶囊按钮右侧到屏幕右侧的边距
  let leftWidth = windowWidth - capsulePosition.left; //胶囊按钮左侧到屏幕右侧的边距

  let navigationbarinnerStyle = [
   `color:${color}`,
   //`background:${background}`,
   `height:${navBarHeight + navBarExtendHeight}px`,
   `padding-top:${statusBarHeight}px`,
   `padding-right:${leftWidth}px`,
   `padding-bottom:${navBarExtendHeight}px`
  ].join(';');
  let navBarLeft;
  if ((back && !home) || (!back && home)) {
   navBarLeft = [
    `width:${capsulePosition.width}px`,
    `height:${capsulePosition.height}px`,
    `margin-left:0px`,
    `margin-right:${rightDistance}px`
   ].join(';');
  } else if ((back && home) || title) {
   navBarLeft = [
    `width:${capsulePosition.width}px`,
    `height:${capsulePosition.height}px`,
    `margin-left:${rightDistance}px`
   ].join(';');
  } else {
   navBarLeft = [`width:auto`, `margin-left:0px`].join(';');
  }
  return {
   navigationbarinnerStyle,
   navBarLeft,
   navBarHeight,
   capsulePosition,
   navBarExtendHeight,
   ios,
   rightDistance
  };
 }

 render () {
  const {
   navigationbarinnerStyle,
   navBarLeft,
   navBarHeight,
   capsulePosition,
   navBarExtendHeight,
   ios,
   rightDistance
  } = this.state.configStyle;
  const {
   title,
   background,
   backgroundColorTop,
   back,
   home,
   searchBar,
   searchText,
   iconTheme,
   extClass
  } = this.props;
  let nav_bar__center;
  if (title) {
   nav_bar__center = <text>{title}</text>;
  } else if (searchBar) {
   nav_bar__center = (
    <View
     className='lxy-nav-bar-search'
     style={`height:${capsulePosition.height}px;`}
     onClick={this.handleSearchClick.bind(this)}
    >
     <View className='lxy-nav-bar-search__icon' />
     <View className='lxy-nav-bar-search__input'>{searchText}</View>
    </View>
   );
  } else {
   /* eslint-disable */
   nav_bar__center = this.props.renderCenter;
   /* eslint-enable */
  }
  return (
   <View
    className={`lxy-nav-bar ${ios ? 'ios' : 'android'} ${extClass}`}
    style={`background: ${backgroundColorTop ? backgroundColorTop : background};height:${navBarHeight +
     navBarExtendHeight}px;`}
   >
    <View
     className={`lxy-nav-bar__placeholder ${ios ? 'ios' : 'android'}`}
     style={`padding-top: ${navBarHeight + navBarExtendHeight}px;`}
    />
    <View
     className={`lxy-nav-bar__inner ${ios ? 'ios' : 'android'}`}
     style={`background:${background};${navigationbarinnerStyle};`}
    >
     <View className='lxy-nav-bar__left' style={navBarLeft}>
      {back && !home && (
       <View
        onClick={this.handleBackClick.bind(this)}
        className={`lxy-nav-bar__button lxy-nav-bar__btn_goback ${iconTheme}`}
       />
      )}
      {!back && home && (
       <View
        onClick={this.handleGoHomeClick.bind(this)}
        className={`lxy-nav-bar__button lxy-nav-bar__btn_gohome ${iconTheme}`}
       />
      )}
      {back && home && (
       <View className={`lxy-nav-bar__buttons ${ios ? 'ios' : 'android'}`}>
        <View
         onClick={this.handleBackClick.bind(this)}
         className={`lxy-nav-bar__button lxy-nav-bar__btn_goback ${iconTheme}`}
        />
        <View
         onClick={this.handleGoHomeClick.bind(this)}
         className={`lxy-nav-bar__button lxy-nav-bar__btn_gohome ${iconTheme}}`}
        />
       </View>
      )}
      {!back && !home && this.props.renderLeft}
     </View>
     <View className='lxy-nav-bar__center' style={`padding-left: ${rightDistance}px`}>
      {nav_bar__center}
     </View>
     <View className='lxy-nav-bar__right' style={`margin-right: ${rightDistance}px`}>
      {this.props.renderRight}
     </View>
    </View>
   </View>
  );
 }
}

export default NavBar;

2、NavBar.less

view,
text,
scroll-view,
input,
button,
image,
cover-view {
 box-sizing: border-box;
}
page {
 /* prettier-ignore */
 --height: 44PX; /* 4*2+32 */
 /* prettier-ignore */
 --right: 97PX; /* 10+87 */
 /* prettier-ignore */
 --navBarExtendHeight: 4PX;
 /* prettier-ignore */
 --navBarHeight: 68PX;
 box-sizing: border-box;
}
.lxy-nav-bar .ios {
 /* prettier-ignore */
 --height: 44PX; /* 4*2+32 */
 /* prettier-ignore */
 --right: 97PX; /* 10+87 */
 /* prettier-ignore */
 --navBarExtendHeight: 4PX;
 box-sizing: border-box;
}
.lxy-nav-bar .android {
 /* prettier-ignore */
 --height: 48PX; /* 8*2+32 */
 /* prettier-ignore */
 --right: 96PX; /* 10+87 */
 /* prettier-ignore */
 --navBarExtendHeight: 4PX;
 box-sizing: border-box;
}
.lxy-nav-bar .devtools {
 /* prettier-ignore */
 --height: 42PX; /* 5*2+32 */
 /* prettier-ignore */
 --right: 88PX; /* 10+87 */
 /* prettier-ignore */
 --navBarExtendHeight: 4PX;
 box-sizing: border-box;
}
.lxy-nav-bar__inner {
 position: fixed;
 top: 0;
 left: 0;
 z-index: 5001;
 /* prettier-ignore */
 height: var(--navBarHeight);
 display: flex;
 align-items: center;
 padding-right: var(--right);
 width: 100%;
 /* prettier-ignore */
 padding-top: 20PX;
 /* prettier-ignore */
 padding-bottom:4PX;
 .placeholder {
  position: absolute;
  top: 0;
  left: 0;
  width: 100%;
 }
}
.lxy-nav-bar__inner .lxy-nav-bar__left {
 position: relative;
 width: var(--right);
 /* prettier-ignore */
 height: 32PX;
 /* padding-left: 10PX; */
 /* prettier-ignore */
 margin-left:10PX;
 display: flex;
 align-items: center;
}
.lxy-nav-bar__buttons {
 height: 100%;
 width: 100%;
 display: flex;
 align-items: center;
 /* prettier-ignore */
 border-radius: 16PX;
 border: 1px solid rgba(204, 204, 204, 0.6);
 position: relative;
}
.lxy-nav-bar__buttons.android {
 border: 1px solid rgba(234, 234, 234, 0.6);
}
.lxy-nav-bar__buttons::after {
 position: absolute;
 content: '';
 width: 1px;
 /* prettier-ignore */
 height: 18.4PX;
 background: rgba(204, 204, 204, 0.6);
 left: 50%;
 top: 50%;
 transform: translate(-50%, -50%);
}
.lxy-nav-bar__buttons.android::after {
 background: rgba(234, 234, 234, 0.6);
}
.lxy-nav-bar__button {
 width: 50%;
 height: 100%;
 display: flex;
 /* prettier-ignore */
 font-size: 12PX;
 background-repeat: no-repeat;
 background-position: center center;
 background-size: 1em 2em;
}

.lxy-nav-bar__inner .lxy-nav-bar__left .lxy-nav-bar__btn_goback:active,
.lxy-nav-bar__inner .lxy-nav-bar__left .lxy-nav-bar__btn_gohome:active {
 opacity: 0.5;
}
.lxy-nav-bar__inner .lxy-nav-bar__center {
 /* prettier-ignore */
 font-size: 17PX;
 /* prettier-ignore */
 line-height: 17PX;
 text-align: center;
 position: relative;
 flex: 1;
 display: -webkit-box;
 display: -webkit-flex;
 display: flex;
 align-items: center;
 justify-content: center;
 /* prettier-ignore */
 padding-left: 10PX;
 text {
  margin-top: -2px;
  font-size:34px;
  font-weight:550;
  line-height:44px;
 }
}
.lxy-nav-bar__inner .lxy-nav-bar__loading {
 font-size: 0;
}
.lxy-nav-bar__inner .lxy-nav-bar__loading .lxy-loading {
 margin-left: 0;
}
.lxy-nav-bar__inner .lxy-nav-bar__right {
 /* prettier-ignore */
 margin-right: 10PX;
}
.lxy-nav-bar__placeholder {
 height: var(--navBarHeight);
 background: #f8f8f8;
 position: relative;
 z-index: 50;
 visibility: hidden;
}

.lxy-nav-bar-search {
 width: 100%;
 height: 100%;
 display: flex;
 justify-content: center;
 align-items: center;
 width: 100%;
 /* prettier-ignore */
 height: 32PX;
 /* prettier-ignore */
 border-radius: 16PX;
 position: relative;
 background: #f6f6f6;
}

.lxy-nav-bar-search__input {
 height: 100%;
 display: flex;
 align-items: center;
 color: #999;
 /* prettier-ignore */
 font-size: 15PX;
 /* prettier-ignore */
 line-height: 15PX;
}
.lxy-nav-bar__inner .lxy-nav-bar__left .lxy-nav-bar__btn_goback {
}
.lxy-nav-bar__inner .lxy-nav-bar__left .lxy-nav-bar__btn_goback.white {
}
.lxy-nav-bar__inner .lxy-nav-bar__left .lxy-nav-bar__btn_gohome {
 /* prettier-ignore */
 background-size: 17PX 34PX;
 margin-top: 10px;
}
.lxy-nav-bar__inner .lxy-nav-bar__left .lxy-nav-bar__btn_gohome.white {
 /* prettier-ignore */
 background-size: 17PX 34PX;
 margin-top: 10px;
}
.lxy-nav-bar-search__icon {
 /* prettier-ignore */
 width: 22PX;
 /* prettier-ignore */
 height: 22PX;
 display: flex;
 align-items: center;
 justify-content: center;
 background-repeat: no-repeat;
 background-size: cover;
}
input{
  padding:0 20px !important;
  text-align: start !important;
}

属性:

在这里插入图片描述

slot:

在这里插入图片描述

到此这篇关于Taro小程序自定义顶部导航栏的文章就介绍到这了,更多相关小程序自定义导航栏内容请搜索自学编程网以前的文章或继续浏览下面的相关文章希望大家以后多多支持自学编程网!

编程技巧
